| DISPLAY | MODEL | ES6508128 | ES7508128 | ||||||
|---|---|---|---|---|---|---|---|---|---|
|
Panel Size Respond Time Visual or Aspect Ratio Panel Type Max Visual Area Resolution Frequency/Refresh rate Display Colors Color Saturability Contrast Ratio (Type) Viewing Angle Brightness Life Span |
65'' 4 ms 16:9 DLED IPS PANEL 1432(H) X 807(V) mm 3840(H) X 2160(V) 60 Hz 1.078 (10 BIT) 72% 4000:1 178°(H/V) 400 cd/m 2 >50,000 hours |
75'' 4 ms 16:9 DLED IPS PANEL 1650(H) X 928(V) mm 3840(H) X 2160(V) 60 Hz 1.078 (10 BIT) 72% 4000:1 178°(H/V) 400 cd/m 2 >50,000 hours |
|||||||
| IO AUD |
|||||||||
| Speaker | 2 x 20w | 2 x 20w | |||||||
| TOUCH PARAMETER | |||||||||
|
Touch Specification Support Systems Touch Points Min. Identifier Input Mode Respond Time Touch Depth Writing Height Writing Display Output Cordinates System Version |
Non-contact infrared sensing technology Windows 10/ Windows 8 /Windows 7 /Windows XP/Android/Linux/Mac OS X/Chrome 20 Touch Points 2 mm Opaque object (finger,pen,etc) < 10 ms +1 mm < 3 mm Single stylus pen two-colour 32767(W) x 32767(D) Android 11.0 upgradable to Android 13 |
Non-contact infrared sensing technology Windows 10/ Windows 8 /Windows 7 /Windows XP/Android/Linux/Mac OS X/Chrome 20 Touch Points 2 mm Opaque object (finger,pen,etc) < 10 ms +1 mm < 3 mm Single stylus pen two-colour 32767(W) x 32767(D) Android 11.0 upgradable to Android 13 |
|||||||
| SYSTEM | |||||||||
|
CPU GPU RAM ROM |
Quad Core A55 2.1 GHz Mail G52MP2 8 GB 128 GB System Storage |
Quad Core A55 2.1 GHz Mail G52MP2 8 GB 128 GB System Storage |
|||||||
| WIRELESS | |||||||||
| Bluetooth | Version - 5.0 Working Frequency - 2.4 GHz Working Distance - 0-10 m Remark - Via the wireless module SI07B |
Version - 5.0 Working Frequency - 2.4 GHz Working Distance - 0-10 m Remark - Via the wireless module SI07B |
|||||||
| WI-FI | Version - 802.11ac/b/g/n/a/ax Working Frequency - 2.4 GHz/5 GHz Working Distance - upto 10 m Remark - Via the wireless module SI07B |
Version - 802.11ac/b/g/n/a/ax Working Frequency - 2.4 GHz/5 GHz Working Distance - upto 10 m Remark - Via the wireless module SI07B |
|||||||
| REAR I/O INTERFACE | |||||||||
|
HDMI IN USB 2.0 USB 3.0 USB Touch Port Audio IN Line OUT Optical OUT RS 232 LAN RJ45 OUT LAN RJ45 IN |
2 1 2 1 1 1 1 1 1 1 |
2 1 2 1 1 1 1 1 1 1 |
|||||||
| FRONT INTERFACE | |||||||||
|
USB3.0 TOUCH USB HDMI I Type-C |
2 1 1 1 (Full functional is Optional) |
2 1 1 1 (Full functional is Optional) |
|||||||
| POWER | |||||||||
|
Voltage Max.power consumpation Standby power consumpation |
100-240~50/60Hz 4A 280W >0.5W |
100-240~50/60Hz 4A 350W >0.5W |
|||||||
| STRUCTURE | |||||||||
|
Bare Dimension Packing Dimension Machine + wall mount thickness Net Weight Gross Weight |
1488.4x896.6x87.2 mm 1630x220x1050 mm 116.5 mm (WIB9060G) 45 KG 65 KG |
1709x1020x88 mm 1860x220x1160 mm 118 mm (WIB9060G) 58 KG 68 KG |
|||||||
| ENVIRONMENT | |||||||||
|
Working temprature Working humidity Storage temprature Stotage humidity Working elevation |
0°C~40°C 10%~90%RH -20°C~60°C 10%~90%RH < 5000m |
0°C~40°C 10%~90%RH -20°C~60°C 10%~90%RH < 5000m |
|||||||
